M27500/GS27500 and Glenair Signature Multi-Conductor Cable

GS27500
ANSI/NEMA WC 27500 Type Electrical Cable

• MIL-STAR Multi-Conductor Cable

968-001
27500 Type With Specialty Braid

• Weight Savings Analysis
  Machine-Braided GS27500 Wire with Standard Nickel Overbraid Versus ArmorLite or AmberStrand Overbraid

968-003GS27500
Cable with Custom Color / Stripe Options and Shield / Braid Material Options

• AS27500 Type Cable

961-066 and 961-067
High-Voltage Duralectric™ FEP-Insulated Wire

With Glenair signature Duralectric FEP insulation for high-voltage applications

• 961-066
  Dual-layer Duralectric insulation and jacket, silver-coated high-strength copper conductor
• 961-067
  Duralectric insulated wire, silver-coated copper conductor

967-028
Tin Coated Wire, 1000V Copper Conductor, Crosslinked Modified ETFE Insulation

• Conductor is tin coated copper per AS29606.
• Insulation is crosslinked modified ETFE (Ethylene-tetrafluoroethylene).
• Color code per MIL-STD-681. See MIL-STD-681 for additional wire color codes.
• Consult factory for custom stripe color order.
• Testing per QCD-967-028-SCC for silver/copper, QCD-967-028-NCC for nickel/copper, and QCD-967-028-TCC for tin/copper.
