PowerPlay™ High-Power Connectors and Cables

A Complete Ecosystem of Lightweight Vibration- and Shock-Resistant Connectors, Contacts, and Cables

Series 973

PowerPlay is a high-power, single-pole and multipole connector series — with four different circular and rectangular packaging options: SuperNine Series III triple-start, SuperNine Series I bayonet, Series 806 micro-miniature, and Micro-Crimp precision rectangular. The connector series combines Glenair signature raised tower insert architecture, Crown Ring contacts, and TurboFlex cable compatibility into the interconnect industry's most innovative power solution. PowerPlay's high-conductivity Crown Ring contact and dielectric insert technology delivers 5,000 VAC dielectric withstanding voltage. Raised safe-touch socket tower and available safe-touch pin meets industry protection requirements for high power distribution applications.

5000 VAC dielectric withstanding voltage
High current, low-resistance, and superior vibration performance
Safe-touch finger-proofing
Integrated band platform cable shield termination
Compatible with TurboFlex high-flexibility cable
Support for bus-bar and other wire terminations
Multi-pin arrangements for size 8 and 4 AWG contacts. Single-pole arrangements for 2, 1/0, 2/0, and 4/0 contacts. Options for 20 AWG interlock contacts on all sizes

Reference

PowerPlay™

PowerPlay™ High-Power Connectors and Cables

A Complete Ecosystem of Lightweight Vibration- and Shock-Resistant Connectors, Contacts, and Cables

Series 973

eBook
PDF (Single pages, print friendly)

On this page...

SuperNine Series I and III PowerPlay™
Series 806 Mil-Aero High-Density PowerPlay
Series 971 Micro-Crimp PowerPlay Rectangular Connectors
TurboFlex High-Current, High-Power Cables
Series 850 High-Power Crown Ring Contacts

SuperNine Series I and III PowerPlay™

SuperNine Series I & III Raised Tower Architecture
High-Temperature Crown Ring Contacts
Compatible TurboFlex Cabling

Reference: SuperNine Series I and III PowerPlay

	973-001 G6 Plug Connector Weights SuperNine Series III PowerPlay Triple-Start
	973-001 00, D0, CS Panel-Mount Receptacles Connector Weights SuperNine Series III PowerPlay Triple-Start
	973-001 07 Jam-Nut Receptacle Connector Weights SuperNine Series III PowerPlay Triple-Start
	973-001 05 In-Line Receptacle Connector Weights SuperNine Series III PowerPlay Triple-Start
	973-002 00, D0, CS Panel-Mount Receptacles SuperNine Series III PowerPlay with Lug Style Contact
	973-002 07 Jam-Nut Mount Receptacle SuperNine Series III PowerPlay with Lug Style Contact
	973-003 00, D0, CS Panel-Mount Receptacles SuperNine Series III PowerPlay with Threaded Contacts
	973-003 07 Jam-Nut Receptacle SuperNine Series III PowerPlay with Threaded Contacts
	973-005 Bulkhead Feedthru Connector SuperNine Series III PowerPlay Triple-Start
	973-006 00, D0, CS Panel-Mount Receptacle Connectors SuperNine Series III PowerPlay with PC Tail Contacts
	973-006 07 Jam-Nut Receptacle SuperNine Series III PowerPlay with PC Tail Contacts
	660-137 Receptacle Cover SuperNine Series III PowerPlay Triple-Start
	660-023 Plug Cover SuperNine Series III PowerPlay Triple-Start
	620H*011 Saddle Clamp, General Purpose SuperNine Series III PowerPlay Triple-Start
	870H001 Swing-Arm Saddle Clamp SuperNine Series III PowerPlay Triple-Start
	870H004 Swing-Arm Saddle Clamp, Composite, EMI Banding SuperNine Series III PowerPlay Triple-Start
	390H*055 EMI+Environmental Backshell, Self-Locking SuperNine Series III PowerPlay Triple-Start
	973-004 G6 Plug with EMI Spring SuperNine Series I Bayonet PowerPlay Connector
	973-004 00, D0, CS Panel-Mount Receptacles SuperNine Series I Bayonet PowerPlay Connector
	973-004 07 Jam-Nut Receptacle SuperNine Series I Bayonet PowerPlay Connector
	660-140 Plug Cover SuperNine Series I Bayonet PowerPlay Connector
	660-141 Receptacle Cover SuperNine Series I Bayonet PowerPlay Connector
	870H001 Swing-Arm Saddle Clamp SuperNine Series I Bayonet PowerPlay Connector
	870H004 Swing-Arm Saddle Clamp, Composite, EMI Banding SuperNine Series I Bayonet PowerPlay Connector
	390H*055 EMI+Environmental Backshell, Self-Locking SuperNine Series I Bayonet PowerPlay Connector

Series 806 Mil-Aero High-Density PowerPlay

Save Size and Weight with Series 806 Versus D38999

Series 806 Mil-Aero is the Glenair micro miniature circular series offering significant size and weight savings while meeting key performance benchmarks for a broad range of applications such as commercial and military aerospace, industrial robotics, and transportation systems. Designed for general use in harsh vibration, shock, and environmental settings—as well as high-altitude, unpressurized aircraft zones with aggressive voltage ratings and altitude immersion standards—the Series 806 Mil-Aero features numerous mechanical design innovations including durable mechanical insert retention, radial seals and triple-ripple grommet seals. Its reduced thread pitch and re-engineered ratchet prevent decoupling problems, particularly in small shell sizes, solving one of the major problems of shell size 9 and 11 MIL-DTL-38999 Series III connectors. PowerPlay versions of the Series 806 leverage all of these performance and design advantages, combined with support for PowerPlay contacts, safe-touch inserts, and TurboFlex cable.

Series 806 Mil-Aero Raised Tower Architecture
High-Temperature Crown Ring Contacts
Compatible TurboFlex Cabling

Reference

	806-091 Plug Connector Series 806 Mil-Aero PowerPlay
	806-092 Square-Flange Receptacle Connector Series 806 Mil-Aero PowerPlay
	806-093 Jam-Nut Receptacle Connector Series 806 Mil-Aero PowerPlay
	667-440, 667-441, 667-443 Receptacle and Plug Covers 667-440 = Receptacle Cover 667-441 = Plug Cover 667-443 = Receptacle Cover, Self-Locking Series 806 Mil-Aero PowerPlay
	627V234 Composite Swing-Arm® Flex Strain Relief with EMI Adapter Series 806 Mil-Aero PowerPlay
	620V*080 Metal Strain Relief Cable Clamp Series 806 Mil-Aero PowerPlay
	380V*143 Metal EMI/RFI Full Radius Profile Backshell 380VS143 = EMI Backshell, Straight 380VM143 = EMI Backshell, 45° 380VN143 = EMI Backshell, 90° Series 806 Mil-Aero PowerPlay

Series 971 Micro-Crimp PowerPlay Rectangular Connectors

High-Power Rectangular Connector for Propulsion Applications

The Series 971 Micro-Crimp PowerPlay is a signature Glenair rectangular power connector, purpose-designed for electrical and hybrid electrical aircraft propulsion applications. The series is equipped with a unique rasied tower architecture for improved creep path electrical performance. Series 971 is equipped with the Glenair high-temperature and high-shock resistant Crown Ring power contact and is fully compatible with ultra high flexibility TurboFlex cable. Supplied in nine high-density power insert arrangements with #8, #4, #2, and #1/0 contacts. Interlock last-mate / first-break arrangements with conventional #20 contacts are also supported. Raised socket towers and safe-touch pin contacts ensure operator safety. Connector shells and bodies are precision-machined from aluminum or stainless steel material and are fully shrouded for electromagnetic compatibility. Full environmental sealing ensures life-of-system reliability in even the harshest high-altitude environments.

Series 971 Rectangular with Raised Tower Architecture
High-Temperature Crown Ring Contacts
Compatible TurboFlex Cabling

Reference

	971-010 Rectangular Plug with Safe-Touch Crimp-Removable Contacts Micro-Crimp PowerPlay Rectangular Plug with Crimp Removable Contacts
	971-011 Rectangular Receptacle with Crimp-Removable Crown Ring Contacts Rear-Mount, Micro-Crimp PowerPlay Rectangular Receptacle
	971-013 Rectangular Rear-Mount Receptacle for Bus-Bar Termination Micro-Crimp PowerPlay Rectangular Receptacle Connector, Rear Mount for Bus-Bar Termination
	971-016 Rectangular Rear Float-Mount Receptacle with Crimp-Removable Contacts Rear Float Mount Micro-Crimp PowerPlay Rectangular Receptacle Connector with Crimp-removable Contacts
	971-017 Rectangular Rear Blind-Mate Receptacle with Crimp-Removable Contacts Blind Mate, Rear Mount Micro-Crimp PowerPlay Rectangular Receptacle Connector with Crimp-removable Contacts

TurboFlex High-Current, High-Power Cables

TurboFlex is an ultra flexible and rugged power cable solution ideal for high-power electrical distribution and propulsion applications such as battery-plant-to-inverter-to-electric-motor cables for eVTOL aircraft. Constructed from rope-lay configuration copper or aluminum wire and jacketed with Glenair signature Duralectric insulation, TurboFlex cables are optimized for use in an ecosystem of Glenair signature contact and connector technologies. Turnkey connectorized or lugged cable assemblies — fully tested and ready for immediate use — provide reliable high-temperature tolerant performance up to 4500 VAC.

Reference

	967-600 Imperial TurboFlex® M AS22759-Type Conductor, Duralectric™ D Insulation, 725-2875 VAC TurboFlex M, with mil-spec conductor per AS29606 provides flight heritage and the stiffness required in some installations, while Duralectric D Insulation provides more flexibility than standard mil-spec wire. 725-2875 VAC, 2450-6750 VDC-rated performance. TurboFlex M AS22759 Type Conductor with Duralectric D Insulation
	967-601 Imperial TurboFlex® M Copper Core, Dual-Layer Duralectric™ D Jackets and Metallic Braided Shield, 725-2875 VAC TurboFlex M, with mil-spec conductor per AS29606 provides flight heritage and the stiffness required in some installations, while Duralectric D Insulation provides more flexibility than standard mil-spec wire. 725-2875 VAC, 2450-6750 VDC-rated performance. TurboFlex M AS22759 Type Conductor with Duralectric D Insulation and Jacket and Braided EMI Shielding
	967-602 Imperial TurboFlex® M Copper Core, Duralectric™ D Insulation, Metallic Braided Shield, Fabric Overbraid 725-2875 VAC TurboFlex M, with mil-spec conductor per AS29606 provides flight heritage and the stiffness required in some installations, while Duralectric D Insulation provides more flexibility than standard mil-spec wire. 725-2875 VAC, 2450-6750 VDC-rated performance. Fabric overbraid provides abrasion and temperature protection. TurboFlex M AS22759 Type Conductor with Duralectric D, Shield, and Fabric Overbraid
	967-022 TurboFlex® M Copper Core, Lightweight Duralectric™ L Insulation, 2000 VAC High-Voltage TurboFlex M Hookup Wire with Duralectric Light Insulation
	967-024 TurboFlex® M Copper Core, Lightweight Duralectric™ L Insulation / Jacket, Metallic Braided Shield, 2000 VAC High-Voltage TurboFlex M Shielded Hookup Wire with Duralectric Light Insulation
	961-106-2000 Imperial TurboFlex® R Copper Core, Duralectric™ D Insulation, 2000 VAC TurboFlex Single-Wall Hookup Wire
	961-107-2000 Imperial TurboFlex® R Copper Core, Duralectric™ D Insulation and Jacket, 2000 VAC TurboFlex Dual-Wall Interconnect Cable
	961-108-2000 Imperial TurboFlex® R Copper Core, Duralectric™ L Insulation, 2000 VAC TurboFlex Single-Wall Hookup Wire

Series 850 High-Power Crown Ring Contacts

For Reduced Contact Resistance, Superior Conductivity, and Higher Temperature-Tolerance than Conventional AS39029 Contacts and Specialized High-Power Contacts from Other Manufacturers

Reference

Overview: Crown Ring Contact / Raised Tower Insulator Architecture

	850-325 Crown Ring Pin Contacts for Micro-Crimp PowerPlay and SuperNine I and III PowerPlay Contacts are for use in Series 971 Micro-Crimp PowerPlay and 973 SuperNine PowerPlay connectors.
	850-326 Crown Ring Socket Contacts for Micro-Crimp PowerPlay and SuperNine I and III PowerPlay Contacts are for use in Series 971 Micro-Crimp PowerPlay and 973 SuperNine PowerPlay connectors.
	850-305 Crown Ring Socket Contacts for Series 806 PowerPlay Contacts are for use in Series 806 PowerPlay connectors accepting socket contacts.
	850-202-20 Standard 850-346-20 Extended-Length #20 Pin Contacts for Micro-Crimp PowerPlay and SuperNine I and III PowerPlay Contacts are for use in Series 971 Micro-Crimp PowerPlay and 973 SuperNine PowerPlay connectors. 850-202-20 Size #20 Standard-Length Pin Contact 850-346-20 Size #20 Extended-Length Pin Contact For Interlock First-Mate / Last-Break Applications
	850-347-20 AS39029/56 Type Crimp Socket Contact for Micro-Crimp PowerPlay and SuperNine I and III PowerPlay 850-202-20 Size #20 Standard-Length Pin Contact
	850-356 Size #16 and Size #12 Pin Contacts for Series 806 Mil-PowerPlay Connectors Contacts are for use in Series 806 PowerPlay connectors accepting pin contacts.
	809-111 Size #16 Socket Contacts for Series 806 PowerPlay Connectors Contacts are for use in Series 806 PowerPlay connectors accepting socket contacts. Standard size #16 contacts accept #16 to #20 AWG wire. At rated test current of 13 amps, the maximum voltage drop is 49 millivolts. Contacts are gold-plated copper alloy. Socket contacts feature stainless steel hoods to protect against probe damage. Approved to SAE-AMS-39029. Contacts are bulk packaged. Terminate with M22520/1-01 crimper and M22520/1-04 positioner.
	809-113 Size #12 Socket Contacts for Series 806 PowerPlay Connectors Contacts are for use in Series 806 PowerPlay connectors accepting socket contacts. Standard size #12 contacts accept #12 to #14 AWG wire. At rated test current of 23 amps, the maximum voltage drop is 63 millivolts. Contacts are gold-plated copper alloy. Socket contacts feature stainless steel hoods to protect against probe damage. Approved to SAE AS39029. Contacts are bulk packaged. Terminate with M22520/1-01 crimper and M22520/1-04 positioner.
	850-159 and 850-158 Size #8 Pin and Socket Contacts for Series 806 PowerPlay Connectors Size #8 contacts accept #8 AWG wire. Compatible with Series 806 connectors with size 8 contact cavities. Crimp termination. Bulk packaged. Contacts are for use in Series 806 PowerPlay connectors accepting pin and socket contacts. Military grade Gold plating
	850-094 and 850-095 Size #22HD Pin and Socket Contacts for Series 806 PowerPlay Connectors High-density size #22HD contacts accept #22 to #30 AWG wire. Compatible with Series 806 connectors with size 22HD contact cavities. Crimp termination. Contacts are bulk packaged. Contacts are for use in Series 806 PowerPlay connectors accepting pin and socket contacts. Military grade Heavy gold plating
	850-325 Pin 850-326 Socket Crown Ring Contact Crimp Tooling
	Crown Ring Contact Termination, Installation, and Removal How to Terminate, Install, and Remove Crown Ring Contacts
